Sensaheat is the trusted name in pool and spa heating. The Sensaheat product range has been developed by one of Australia’s leading and most trusted pool and spa suppliers Spa-Craft.
The Sensaheat range of pool & spa heaters have been specifically designed to cater for Australian and New Zealand pool & spa owners, ensuring optimum performance and many years of trouble-free operation.
Sensaheat is proudly Australian own and operated.
Popular Sensaheat product categories
- Downloads
- Error Codes & Messages
Data Sheets
User Manuals
Product fault codes and messages
Error Codes
|
Fault
|
Description
|
|
|---|---|---|
|
E1
|
Water pressure too high
|
|
|
E2
|
Water pressure too low
|
|
|
E3
|
No water flow
|
|
|
E4
|
3 phase power error (3 phase units only)
|
|
|
E5
|
Power supply excess operation range (input voltage too high or too low)
|
|
|
E6
|
Excessive temperature difference between inlet and outlet
|
|
|
E7
|
Water outlet temp too high or too low
|
|
|
E8
|
High exhaust temp
|
|
|
EA
|
Heat exchange or evaporator overheat
|
|
|
Eb
|
Ambient temperature too high or too low
|
|
|
Ed
|
Anti-Freezing reminder
|
|
Sensor Faults
|
Fault
|
Description
|
|
|---|---|---|
|
P0
|
Controller communications failure
|
|
|
P1
|
Water inlet temp sensor failure
|
|
|
P2
|
Water outlet temp sensor failure
|
|
|
P3
|
Gas exhaust temp sensor failure
|
|
|
P4
|
Evaporator coil pipe temp sensor failure
|
|
|
P5
|
Gas return temp sensor failure
|
|
|
P6
|
Cooling coil pipe temp sensor failure
|
|
|
P7
|
Ambient temp sensor failure
|
|
|
P8
|
Cooling plate temp sensor failure
|
|
|
P9
|
Current sensor failure
|
|
|
PA
|
Reset memory failure
|
|
Hardware Faults
|
Fault
|
Description
|
|
|---|---|---|
|
F1
|
Compressor driver module failure
|
|
|
F2
|
PFC Module failure
|
|
|
F3
|
Compressor start failure
|
|
|
F4
|
Compressor running failure
|
|
|
F5
|
Inverter board over current
|
|
|
F6
|
Inverter board overheat
|
|
|
F7
|
Current protection
|
|
|
F8
|
Cooling plate overheat
|
|
|
F9
|
Fan motor failure
|
|
|
FA
|
PFC module over current
|
|
|
FB
|
Power filter plate no power
|
|
